  1. Hitachi
  2. Ranges
  3. Cassette AC
  4. Fixed Speed Series

– Fixed Speed Series

It has fabulous features like Fresh Air Intake, Sleep & Timer Control, Dimensional Screw Fan.



  • TYPE​: Cassette Air Conditioner Series​
  • STAR RATING: 1 Star / 3 Star​
Fixed Speed Series_header
It has fabulous features like Fresh Air Intake, Sleep & Timer Control, Dimensional Screw Fan.
Fixed Speed Series_0

– Sleep & Timer Control

Sleep & Timer Control


Fixed Speed Series_1

– Dry Mode

Decreases room humidity by softly cooling the room.
Fixed Speed Series_2

– Fresh Air Intake provision

Fresh Air Intake provision
Fixed Speed Series_3

– Dimensional Screw Fan

Dimensional Screw Fan
Fixed Speed Series_4

– On/Off timer with advanced Startup

The smart technology that reaches desired set temperature automatically at preset time.

– Other Features


  • 100% Inner Grooved Copper Tube

  • Tropical Design

  • 43 Quality Tests

  • Remote Control

– Tech Data

Fixed Speed Cassette

Fixed Speed Cassette Fixed Speed Cassette Fixed Speed Cassette Fixed Speed Cassette Fixed Speed Cassette Fixed Speed Cassette Fixed Speed Cassette Fixed Speed Cassette Fixed Speed Cassette Fixed Speed Cassette Fixed Speed Cassette
Details Model Number
Star Rating
Compressor Type / Refrigerant
Performance Rated Cooling Capacity (100% load) BTU / Hr
Rated Cooling Capacity (100% load) Watts
Maximum Cooling Capacity BTU/Hr
Maximum Cooling Capacity Watts
Rated ISEER
Annual Power Consumption (As per BEE norms) (kWh)
Fan Speed No. of Steps
Air Flow (IDU) (Cooling-Super High) CFM (HIGH)
Sound Level * dBA (H / L)
Electrical Rated Power Input - Cooling Watts
Rated Power Supply Volts / Hz / Phase
Rated Current Drawn Amps
Dimensions Dimension (IDU) (W X H X D) mm
Dimension (ODU) (W X H X D) mm
Dimension (Panel) (W X H X D) mm
Net Weight-IDU / ODU Kg
RAG318HYDA
3
Rotary / R410a
18000
5275
-
-
3.6
1134
4
550
37
1465
230 / 50 / 1
6.5
570 X 260 X 570
792 X 600 X 299
647 X 50 X 647
19 / 45
RAG122HYDA
1
Rotary / R410a
22000
6446
-
-
3.12
1599
4
550
37
2066
230 / 50 / 1
9.33
570 X 260 X 570
792 X 600 X 299
647 X 50 X 647
19 / 48
RAG124HYDA
1
Rotary / R410a
24000
7030
-
-
3.2
1701
4
720
38
2197
230 / 50 / 1
9.75
840 X 205 X 840
792 X 600 X 299
950 X 55 X 950
22 / 50
RAG036HYDA3
NA
Twin Rotary / R410a
36100
10577
-
-
3.25
NA
4
1000
41
3250
400 / 50 / 3
6.5 / Phase
840 X 287 X 840
935 X 735 X 390
950 X 55 X 950
27 / 72
RAG048HYDA3
NA
Twin Rotary / R410a
48000
14064
-
-
3.16
NA
4
1100
41
4450
400 / 50 / 3
9.34 / Phase
840 X 287 X 840
935 X 735 X 390
950 X 55 X 950
27 / 80
RAG318HYD
3
Rotary / R22
18100
5303
-
-
3.7
1109
4
550
37
1433
230 / 50 / 1
6.5
570 X 260 X 570
792 X 600 X 299
647 X 50 X 647
19 / 45
RAG118HYD
1
Rotary / R22
17400
5098
-
-
3.26
1211
4
550
37
1564
230 / 50 / 1
7.1
570 X 260 X 570
792 X 600 X 299
647 X 50 X 647
19 / 45
RAG122HYD
1
Rotary / R22
22000
6446
-
-
3.16
1579
4
550
37
2040
230 / 50 / 1
9.3
570 X 260 X 570
792 X 600 X 299
647 X 50 X 647
19 / 45
RAG124HYD
1
Rotary / R22
24000
7030
-
-
3.2
1701
4
720
38
2197
230 / 50 / 1
9.75
840 X 205 X 840
792 X 600 X 299
950 X 55 X 950
22 / 50
RAG036HYD
NA
Twin Rotary / R22
36100
10577
-
-
3.47
NA
4
1000
41
3050
230 / 50 / 1
14.3
840 X 287 X 840
950 X 740 X 460
950 X 55 X 950
27 / 70
RAG048HYD3
NA
Twin Rotary / R22
48000
14064
-
-
3.16
NA
4
1100
41
4450
400 / 50 / 3
9.34 / Phase
840 X 287 X 840
950 X 740 X 460
950 X 55 X 950
27 / 78
Open table
Download PDF
Download PDF

– Documentation

Manuals, brochures and other product literature. If you need any more information, please get in touch.

All downloads
–
–

– Tech Data

Fixed Speed Cassette

Fixed Speed Cassette Fixed Speed Cassette Fixed Speed Cassette Fixed Speed Cassette Fixed Speed Cassette Fixed Speed Cassette Fixed Speed Cassette Fixed Speed Cassette Fixed Speed Cassette Fixed Speed Cassette Fixed Speed Cassette
Details Model Number
Star Rating
Compressor Type / Refrigerant
Performance Rated Cooling Capacity (100% load) BTU / Hr
Rated Cooling Capacity (100% load) Watts
Maximum Cooling Capacity BTU/Hr
Maximum Cooling Capacity Watts
Rated ISEER
Annual Power Consumption (As per BEE norms) (kWh)
Fan Speed No. of Steps
Air Flow (IDU) (Cooling-Super High) CFM (HIGH)
Sound Level * dBA (H / L)
Electrical Rated Power Input - Cooling Watts
Rated Power Supply Volts / Hz / Phase
Rated Current Drawn Amps
Dimensions Dimension (IDU) (W X H X D) mm
Dimension (ODU) (W X H X D) mm
Dimension (Panel) (W X H X D) mm
Net Weight-IDU / ODU Kg
RAG318HYDA
3
Rotary / R410a
18000
5275
-
-
3.6
1134
4
550
37
1465
230 / 50 / 1
6.5
570 X 260 X 570
792 X 600 X 299
647 X 50 X 647
19 / 45
RAG122HYDA
1
Rotary / R410a
22000
6446
-
-
3.12
1599
4
550
37
2066
230 / 50 / 1
9.33
570 X 260 X 570
792 X 600 X 299
647 X 50 X 647
19 / 48
RAG124HYDA
1
Rotary / R410a
24000
7030
-
-
3.2
1701
4
720
38
2197
230 / 50 / 1
9.75
840 X 205 X 840
792 X 600 X 299
950 X 55 X 950
22 / 50
RAG036HYDA3
NA
Twin Rotary / R410a
36100
10577
-
-
3.25
NA
4
1000
41
3250
400 / 50 / 3
6.5 / Phase
840 X 287 X 840
935 X 735 X 390
950 X 55 X 950
27 / 72
RAG048HYDA3
NA
Twin Rotary / R410a
48000
14064
-
-
3.16
NA
4
1100
41
4450
400 / 50 / 3
9.34 / Phase
840 X 287 X 840
935 X 735 X 390
950 X 55 X 950
27 / 80
RAG318HYD
3
Rotary / R22
18100
5303
-
-
3.7
1109
4
550
37
1433
230 / 50 / 1
6.5
570 X 260 X 570
792 X 600 X 299
647 X 50 X 647
19 / 45
RAG118HYD
1
Rotary / R22
17400
5098
-
-
3.26
1211
4
550
37
1564
230 / 50 / 1
7.1
570 X 260 X 570
792 X 600 X 299
647 X 50 X 647
19 / 45
RAG122HYD
1
Rotary / R22
22000
6446
-
-
3.16
1579
4
550
37
2040
230 / 50 / 1
9.3
570 X 260 X 570
792 X 600 X 299
647 X 50 X 647
19 / 45
RAG124HYD
1
Rotary / R22
24000
7030
-
-
3.2
1701
4
720
38
2197
230 / 50 / 1
9.75
840 X 205 X 840
792 X 600 X 299
950 X 55 X 950
22 / 50
RAG036HYD
NA
Twin Rotary / R22
36100
10577
-
-
3.47
NA
4
1000
41
3050
230 / 50 / 1
14.3
840 X 287 X 840
950 X 740 X 460
950 X 55 X 950
27 / 70
RAG048HYD3
NA
Twin Rotary / R22
48000
14064
-
-
3.16
NA
4
1100
41
4450
400 / 50 / 3
9.34 / Phase
840 X 287 X 840
950 X 740 X 460
950 X 55 X 950
27 / 78
Open table
Download PDF
Download PDF
Equipment
  • Cassette AC
  • Chillers
  • Ducted Air Conditioners
  • Ductless Air Conditioners
  • Fixed Speed Split AC
  • Hot & Cold AC
  • Inverter Split AC
  • Refrigerators
  • Ventilation
  • VRF Controllers
  • VRF Indoor Unit
  • VRF Outdoor Unit
  • Window AC
Useful links
  • E-Shop
  • Resources
  • About Us
  • Contact us
  • Hitachi Air Conditioner App
  • Magazine
  • Faqs
  • Sign in
  • Legal & Cookies Policies
  • Privacy Policy

© 2022 Johnson Controls - Hitachi Air Conditioning Company

Need help? Chat with us!
–
