SUMMIT PED WALL MOUNTED

– SUMMIT PED WALL MOUNTED

High efficiency, low maintenance, zero fuss

– 01. ENERGY SAVING

Eco Mode efficiently maintains the perfect temperature, delivering the energy saving performance which earned the E-Series models their A+ seasonal energy efficiency rating.

– 02. FRESHER AIR

– 03. ALL-SEASON COMFORT

When it’s cooler outside, the heat pump system delivers low-energy heating with minimal maintenance. In milder climates, it can even replace alternative heating systems.

– Outdoor Units

Wall Mounted Summit - R32

RAK-18PED	RAK-25PED	RAK-35PED	RAK-50PED

Nominal Capacity (min - max)	Cooling	KW
Nominal Capacity (min - max)	Heating	KW

Seasonal energy rating	Cooling
Seasonal energy rating	Heating

SEER

SCOP

EER - COP (Cooling/heating energy label)

Sound Pressure (very low - low - med - high)	Cooling	dB(A)
Sound Pressure (very low - low - med - high)	Heating	dB(A)

Sound Power (Eurovent data)

dB(A)

Air flow (very low - low - med - high)	Cooling	m3/h
Air flow (very low - low - med - high)	Heating	m3/h

Diameter of pipes (liquid-gas)

Inches

Condensate drain diameter

Remote control (standard)

Programming

Dimensions	Height	mm
	Width	mm
	Depth	mm

Weight

2,00 (0,90-2,50)
2,50 (0,90-3,20)
A+
A
5.8
3.8
3,45-4,03 (A/A)
21-24-33-37
19-22-33-38
51
312-350-400-440
312-350-420-480
1/4 - 3/8
16
Eco Control
24h / 7 Day
280
780
218
7.5

2,50 (0,90-3,10)
3,40 (0,90-4,40)
A+
A
5.8
3.8
3,57-3,86 (A/A)
22-24-33-40
20-23-34-41
54
333-370-430-510
333-400-500-570
1/4 - 3/8
16
Eco Control
24h / 7 Day
280
780
218
7.5

3,50 (0,90-4,00)
4,20 (0,90-5,00)
A+
A
5.85
3.8
3,21-3,82 (A/A)
25-26-36-43
26-27-36-44
57
333-400-485-600
333-520-550-660
1/4 - 3/8
16
Eco Control
24h / 7 Day
280
780
218
7.5

5,00 (1,90-5,20)
6,00 (2,20 -7,30)
A+
A
5.88
3.8
3,21-3,61 (A/A)
28-30-40-46
25-30-39-47
60
333-450-600-700
433-510-650-770
1/4 - 1/2
16
Eco Control
24h / 7 Day
280
780
218
8

Outdoor Units

RAC-18WED	RAC-25WED	RAC-35WED	RAC-50WED

Power feed

Power consumption (min - max)	Cooling	KW
Power consumption (min - max)	Heating	KW

Sound Pressure	Cooling	dB(A)
Sound Pressure	Heating	dB(A)

Sound Power

dB(A)

Airflow	Cooling	m3/h
Airflow	Heating	m3/h

Diameter of pipes (liquid-gas)

Inches

Maximum pipe length

Maximum piping elevation (between IDU & ODU)

Refrigerant charge / (Pre-charged length)

kg (m)

Refrigerant

Compressor

Dimensions	Height	mm
	Width	mm
	Depth	mm

Weight

230V, 1Ph, 50Hz
0,58 (0,25-1,01)
0,62 (0,25-0,97)
45
46
59
1860
1620
1/4 - 3/8
20
10
0,72 / (20)
R32
Rotary
530
660
278
24.5

230V, 1Ph, 50Hz
0,70 (0,25-1,29)
0,88 (0,25-1,25)
47
48
61
1860
1620
1/4 - 3/8
20
10
0,72 / (20)
R32
Rotary
530
660
278
24.5

230V, 1Ph, 50Hz
1,09 (0,25-1,46)
1,10 (0,25-1,70)
48
49
62
1860
1620
1/4 - 3/8
20
10
0,95 (20)
R32
Rotary
530
660
278
27.5

230V, 1Ph, 50Hz
1,56 (0,50-2,10)
1,66 (0,50-2,75)
50
50
64
2160
2160
1/4 - 1/2
20
10
1,25 (20)
R32
Rotary
600
792
299
40

Open table

Download PDF
