Gen2 VRF (Heat Pump VRF)

Modular Top Flow Heat Pump VRF

Configure 208/230V, 460V and 575V heat pump systems in multiple ways to design systems up to 36 tons, providing the precise capacity needed with the fewest possible modules.
Gen2 VRF (Heat Pump VRF)_0

Imagine the possibilities


  • Enjoy greater design freedom with connection ratios up to 150% and long refrigerant piping lengths – up to 3,281 feet total pipe run and vertical distance of 360’ when outdoor unit is above indoor unit

  • Design systems with fewer units using our single chassis 6, 8, 10, 12, 14 and 16 ton units

  • Meet diverse application requirements with impressive operating ranges and high capabilities at low and high ambient temperatures

  • Reduce energy consumption with inverter scroll compressors designed for optimum efficiency at partial load conditions and power-saving demand control

  • Enjoy maintenance that's a breeze with diagnostics and malfunction codes available at push of a control panel button

Key features of 6 to 36 ton heat pump

Easy Installation: Hitachi 6 to 36 ton heat pumps are perfect for both new construction and retrofit projects since they are made with quick and simple installation in mind. Locate the local HVAC manufacturer's representative for simple Hitachi Cooling & Heating equipment installation.
Outdoor AC Coils: Large face area outside coils are used by all units. These coils are made of mechanically bonded aluminum plate-type fins and seamless copper tubes, with full drew collars that completely enclose the tubes for maximum operating efficiency.
Heating Section: Numerous electric heat options can efficiently meet the majority of comfort heating needs, from morning warm-up control to full heat. High capacity and impressive working ranges at both low and high ambient temperatures to satisfy a variety of application needs.
AC Control panel: Diagnostics and malfunction codes available at push of a control panel button.
